F-1000UT Van Freezer Units To Frozen For Big Cooling Trucks
Front mounted , F-1000UT , mini truck refrigeration unit , it is driven by the engine of the vehicle , specialized for 9.6 meters long refrigerated compartments to keep frozen (-18℃). Own the best quality accessories with Carrier Technology.
Share With:
Product Description
F-1000UT Van Freezer Units To Frozen For Big Cooling Trucks:
Advantages of truck refrigeration units F-1000UT :
  • a. Double systems : cooling and heating ;
  • b. Automatic defrost ;
  • c. Own the best quality accessories with Carrier Technology
  • d. CPR valve ;
  • e. Condenser with Parallel flow ;
  • f.  Evaporator with inner screw tube and aluminum fin ;
  • g. U-tube heat exchanger ;
  • h. Sheet metal is painted in BMW's foundry in China .
F-1000UT Van Freezer Units To Frozen For Big Cooling Trucks:
Technical Data of truck refrigeration units F-1000UT :

Model

FGS-1000UT



Temperature(℃)

30~ -18℃

Volume (m³)

42



Compressor

model

QP-31

type

swash plate type

displacement (cc/r)

310

lubricating oil

Mobil 68





Cooling capacity (W)



environmental

35℃

0℃

7350

-18℃

3940



Condenser

condenser type

  Parallel flow

fan type

 axial fan

fan number

3

 voltage

DC 12/24

Ultra-thin evaporator



evaporator type

inner screw tube and aluminum fin

fan type

axial fan

fan number

3

voltage

DC 12/24

Throttle type

Danfoss

external equalizer expansion valve

Refrigerant

R404A

Refrigerant charge amount(kg)

5.0KG

Defrost type

hot gas defrost (optional)

Structure

split design and engine driven

Installation type

Front-mounted type

Dimensions (mm)

evaporator

1220*650*320

condenser

1850*335*370

Weight(kg)

203
